CONCEPT DOMAIN - DODAF2 - Data and Information Viewpoint
| Description | DoDAF-described Models within the Data and Information Viewpoint provide a means of portraying the operational and business information requirements and rules that are managed within and used as constraints on the organizations business activities. |
|---|---|
| External references |
 DoDAF2 - Data and Information Viewpoint |
| Dictionary |
SysFEAT - DoDAF 2 |
| Parent Domain |
SysFEAT- DoDAF 2 |
DOMAIN CONCEPT GRAPH
Diagram Graph
| Name | Description |
|---|---|
|
DODAF2 - DIV-1 - Conceptual Data Model |
The required high-level data concepts and their relationships.
|
|
DODAF2 - DV-2 - Logical Data Model |
The documentation of the data requirements and structural business process (activity) rules. In DoDAF V1.5, this was the OV-7. |
|
DODAF2 - DV-3 - Physical Data Model |
The physical implementation format of the Logical Data Model entities, e.g., message formats, file structures, physical schema. In DoDAF V1.5, this was the SV-11. |
